- General Information
- Manufacturer
- Vivotek, Inc
- Manufacturer Website Address
- http://www.vivotek.com
- Brand Name
- Vivotek
- Product Type
- Ethernet Switch
The AW-FGT-100D-120 quipped with DIP switch provides EX mode, ST VLAN, and ST mode. Especially designed for IP Surveillance applications, the camera provides standard 802.3af/at PoE functions in ST mode, while EX mode transmits data & power on one single cable up to 250 meters via EX ports for long-reach PoE IP cameras. The Commercial series adds an extra 20% range of input voltage tolerance(280VAC 4hrs, 300VAC 1 min), lightning surge protection of AC power & PoE surge protection to prevent the damage caused by outside unstable AC power, lightning surge, and power spikes. These unique features reduce costs associated with the replacement of damaged units.
- Interfaces/Ports
- Total Number of Network Ports
- 10
- Modular
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 8 x Fast Ethernet PoE
- 2 x Gigabit Ethernet TP/SFP Combo
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- Fast Ethernet
- Network Technology
- 10/100/1000Base-T
- 10/100Base-T
- 1000Base-X
- I/O Expansions
- Total Number of Expansion Slots
- 2.0
- Expansion Slot Type
- SFP (mini-GBIC)
- Shared SFP Slot
- Yes
- Number of SFP Slots
- 2
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3af
- IEEE 802.3at
- Management & Protocols
- Manageable
- No
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 115 W
- Input Voltage
- 120 V AC
- 230 V AC
- Power Source
- Power Supply
- Power Consumption
- 120 W
- Physical Characteristics
- Height
- 1.7"
- Width
- 7.1"
- Length
- 10.6"
- Weight (Approximate)
- 3.40 lb
- Miscellaneous
- Application/Usage
- IP Surveillance Network
- IP Camera
