- General Information
- Manufacturer
- Ubiquiti Inc.
- Manufacturer Website Address
- http://www.ui.com
- Brand Name
- Ubiquiti
- Product Type
- Wireless Access Point
Enterprise-grade indoor/outdoor access point with 10-stream tri-band WiFi 7 performance, PRISM™ active RF filtering technology, integrated directional antennas, a 10 GbE uplink, and a redundant GbE port for high availability.
- Technical Information
- Wireless LAN Standard
- IEEE 802.11n/ac/ax/be/v/r/k
- Network Band
- Tri Band
- Frequency Band
- 2.40 GHz
- 5 GHz
- 6 GHz
- Total Number of Antennas
- 1
- Number of Internal Antennas
- 1
- Indoor/Outdoor
- Indoor/Outdoor
- Wireless Transmission Speed
- 11.50 Gbit/s
- MIMO Technology
- Yes
- MIMO Type
- Multi User MIMO
- Number of Bandwidth Streams
- 10
- Ingress Protection (IP) Rating
- IPX6/IP67
- High Availability Supported
- Yes
- Interfaces/Ports
- Ethernet Technology
- 10 Gigabit Ethernet
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 2
- PoE PD Port
- Yes
- Network & Communication
- Wi-Fi Generation
- Wi-Fi 7
- Communication Protocols
- RADIUS
- HTTPS
- Power Description
- Power Consumption
- 44 W
- Physical Characteristics
- Form Factor
- Pole-mountable
- Wall Mountable
- Ceiling Mountable
- Antenna Form Factor
- Internal
- Height
- 9.84" (250 mm)
- Width
- 9.84" (250 mm)
- Depth
- 1.79" (45.50 mm)
- Weight (Approximate)
- 4.85 lb (2200 g)
- Miscellaneous
- Package Contents
- E7 Campus
- Mounts
- Waterproof Door Kit
- Certifications & Standards
- FCC
- IC
