High-Density Connectivity with 4× Increased Capacity
OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.
Hospitality
High Quality and Full Coverage Wi-Fi
Restaurant
Full Wi-Fi Coverage in High-Density Environment
Shopping Mall
Social Marketing for O2O
Meeting Room
Wireless and Wired Connections for dense usage
Railway Station
High-Density Wi-F
Advanced Wi-Fi Speed with 4 Spatial Streams
The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.
Omada SDN-Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Hassle-Free Centralized Cloud Management:
100% centralized cloud management of whole network from different sites-all controlled from a single interface anywhere, anytime.
Seamless Roaming
802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Boost Network Efficiency in All Aspects With Rich Advanced Features
Band Steering
Automatically moves dual band devices onto the wider 5GHz band for faster connections.
Load Balance
ensures large numbers of users have smooth network experiences in high-density business networks
Airtime Fairness
Increases average network throughput in heavily congested environments
Easy to Mount with Refined Industrial Design
- push up
- simply rotate to lock
Secure Guest Network with Facebook Wi-Fi and SMS Login
Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- TP-Link
- Product Type
- Wireless Access Point
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Wireless LAN Standard
- 802.11ax
- Network Band
- Dual Band
- Frequency Band
- 2.40 GHz
- 5 GHz
- Wireless Transmission Speed
- 1.76 Gbit/s
- MIMO Technology
- Yes
- Beamforming Technology
- Yes
- Data Encryption
- Yes
- Encryption Standard
- WPA-PSK
- WPA2-PSK
- WEP
- WPA-ENT
- WPA2-ENT
- WPA3-ENT
- WPA3-Personal
- Interfaces/Ports
- Ethernet Technology
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 1
- PoE PD Port
- Yes
- Management Port
- Yes
- Power Description
- Power Consumption
- 13.50 W
- Physical Characteristics
- Form Factor
- Wall Mountable
- Ceiling Mountable
- Antenna Form Factor
- Internal
- Height
- 2.5"
- Width
- 9.6"
- Depth
- 9.6"
- Miscellaneous
- Package Contents
- AX1800 Wireless Dual Band Ceiling Mount Access Point
- Power Adapter
- Ceiling/Wall Mounting Kits
- Installation Guide
- Additional Information
Legal Disclaimer:
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
