The EXR Series offers users a robust and advanced line interactive UPS offering. New features include a higher power factor for improved UPS efficiency, auto-recognition of external battery packs for a smarter extended run-time solution, tool-less battery connection and replacement and so much more!
The EXR Series UPSs offer complete protection from all electrical problems, including spikes, surges, sags, brownouts, and blackouts, in a versatile rack/tower convertible format. True sine wave electrical output ensures the best power for sensitive electronic equipment.
EXR® Key Features
Key Features Include:
- 0.9 power factor - increased capacity without migrating to larger models
- NEW Alphanumeric LCD Dot Matrix display - easy access to key UPS statuses
- UPS configuration options via front panel - make key adjustments utilizing the front panel LCD
- Load shedding - two power banks allow equipment prioritizing for increased runtime
- Independent Battery Bypass™ - provides voltage regulation with surge and spike protection even when batteries are weak or dead.
- Auto-recognition of external battery packs - automatically recalculate runtimes
- Unlimited runtime capability with external battery packs - extended runtime solution to meet any backup power demand
- Flexible installation - rack or tower configurable; wall mount kits available
- Simultaneous USB, RS232, and SNMP communications
- Minuteman® SentryHD™ - UPS monitoring and control software included
- Industry-leading product warranty - featuring a 3-year non-prorated warranty (including batteries)
- Dedicated remote Emergency Power Off (EPO) port
- 120V & 208V - 208V models available (1500 & 3000VA models)
- cULus certification - NOM certification (Mexico)
- RoHS 2 compliant
- Energy Star 2.0 certification
Front LCD Panel
The NEW Alphanumeric LCD Dot-Matrix EXR Series Display
Provides more detailed information about the UPS status than the previous LCD display, including:
- Input and Output Voltage
- Estimated runtime
- UPS Operating Mode
- UPS Self-test results
- Battery Condition
- Display model and serial number
- View load bank status and capacities
- Display battery module part number
- Replace Error Codes with descriptions
The LCD panel is designed so that it can be oriented vertically or horizontally depending on the installation orientation of the UPS.
- General Information
- Manufacturer
- Para Systems, Inc
- Manufacturer Website Address
- http://www.minutemanups.com
- Brand Name
- Minuteman
- Product Series
- EXR
- Product Type
- Line-interactive UPS
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Plug/Connector Type
- NEMA 6-15P
- Receptacle Type
- NEMA 5-15R
- NEMA 6-15R
- Receptacle Detail
- 8 x NEMA 5-15R
- 6 x NEMA 6-15R
- Dataline Protection
- RJ-45
- Phase
- Single Phase
- Application/Usage
- Mission Critical Equipment
- Electronic Equipment
- Data Center
- Network Closet
- Security System
- Education
- Power Description
- Load Capacity (VA)
- 1500 VA
- Load Capacity (Watt)
- 1350 W
- Input Voltage
- 120 V AC
- Input Voltage Range
- 80 V AC - 164 V AC
- Output Voltage
- 120 V AC
- 208 V AC
- Input Frequency
- 60 Hz
- Waveform Type
- True Sine Wave
- Surge Energy Rating
- 1000 J
- Management
- Network Management
- SNMP
- Controls/Indicators
- Status Indicators
Front LCD Panel:
- Input and Output Voltage
- Estimated runtime
- UPS Operating Mode
- UPS Self-test results
- Battery Condition
- Display model and serial number
- View load bank status and capacities
- Display battery module part number
- Replace Error Codes with descriptions
- Interfaces/Ports
- Serial Port
- Yes
- Network (RJ-45)
- Yes
- EPO Port
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Backup/Run Time (Full Load)
- 2.50 Minute
- Backup/Run Time (Half Load)
- 9 Minute
- Hot Swappable
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Maximum Operating Elevation
- 9842.52 ft
- Operating Humidity
- 0% - 95%
- Physical Characteristics
- Height
- 3.5"
- Width
- 19"
- Form Factor
- Tower/Rack/Wall Mountable
- Weight (Approximate)
- 43 lb
- Miscellaneous
- Software Included
- Minuteman SentryHD
- Energy Star
- Yes
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- ENERGY STAR 2.0
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 2
