- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Line
- Pro Centric
- Product Series
- LN766A
- Product Type
- Smart LED-LCD TV
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Screen Size Class
- 16"
- Viewable Screen Size
- 15.6"
- Backlight Technology
- Edge LED
- Operating System
- WebOS 22
- Features
- Instant On
- Welcome Screen
- Pro:Centric Direct
- Pro:Centric
- Pro:Centric V
- Pro:Idiom Digital Right Management (DRM)
- Miracast Technology
- SmartShare
- Web Browser
- Sound Sync
- Touchscreen
- Yes
- Streaming Service
- YouTube
- Web Browser
- Yes
- Video
- Digital Tuner
- ATSC
- ClearQAM
- Analog Tuner
- NTSC
- SECAM
- PAL
- Video Signal Standard
- HDTV
- Maximum Resolution
- 1920 x 1080
- Scan Format
- 1080p
- Aspect Ratio
- 16:9
- High Dynamic Range (HDR)
- Yes
- Viewing Angle
- 160° Horizontal/160° Vertical
- Audio
- Speakers
- Yes
- Number of Speakers
- 2
- RMS Output Power
- 2 W
- Network & Communication
- Wireless LAN
- Yes
- Bluetooth
- Yes
- Interfaces/Ports
- HDMI
- Yes
- HDMI Version
- HDMI 2.0
- Number of HDMI Inputs
- 1
- USB
- Yes
- USB Standard
- USB 2.0
- Digital Audio Output
- No
- Headphone
- Yes
- Network (RJ-45)
- No
- Number of Network (RJ-45) Ports
- 1
- Power Description
- Input Voltage
- 19 V DC
- 100 V AC
- 240 V AC
- Input Voltage Range
- 100 V AC - 240 V AC
- Input Frequency
- 50 Hz
- 60 Hz
- Energy & Performance
- Maximum Operating Power Consumption
- 35 W
- Standby Power Consumption
- 0.5 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 75 x 75
- Height
- 10.97" (279 mm)
- Width
- 15.41" (391 mm)
- Depth
- 1.81" (46 mm)
- Weight (Approximate)
- 6.39 lb (2.90 kg)
- Shipping Weight (Approximate)
- 8.60 lb
- Miscellaneous
- Additional Information
- AI Acoustic Tuning: No
- AI Sound: No
- Clear Voice: No
- One Touch Sound Tuning: No
- Sound Mode: No
- Global IPTV Support (IPStreaming) :Yes
- MPEG-2 / MPEG-4 H.264 Decoding :No
- Audio Out (3.5 mm) :No
- AV In (3.5 mm) :No
- DC In :Yes (x1)
- Debug (3.5 mm) :No
- ECI (RJ12) :No
- IR In (3.5 mm) :Yes (x1)
- IR Out :No
- MPI (RJ12) :Yes (x1)
- Pillow Speaker Interface (6 Pin) :No
- RF / AC In (Power Over Coax) :Yes (x1)
- RF In (Antenna / Cable) :Yes (x1)
- RS-232C (3.5 mm) :No
- RS-232C (D-sub 9-pin) :No
- Service Only (3.5 mm) :No
- TV Link CFG (3.5 mm) :No
- Power Consumption (Typ.) :33W
- Power over Coax (PoC) :20-34 Vac (28 V Typ.) / 22-48 Vdc (24 V Typ.)
- Beacon :No
- Diagnostics :No
- Embedded b-LAN :No
- Energy Saving Mode :No
- External Control Interface :No
- IoT :No
- IR Signal from Receiver (Logic High Pulses) :No
- IR Signal from Receiver (Logic Low Pulses) :No
- LG TV Plus App :No
- Mobile Connection Overlay :No
- Multi-code IR :Yes
- NTP Sync Timer :No
- SI Compatible (TVLink Interactive) :No
- Update Time :No
- USB Data Cloning :No
- VLAN ID :No
- V-Lan Tag :No
- Voice Recognition (Standalone / Solution) :No
- XD Engine :No
- EzManager :No
- Home (Launcher Bar) :No
- Hotel Mode :No
- HTNG-CEC :1.4
- Insert Image :Yes
- Installer Menu :No
- Lock Mode :No
- Motion Eye Care :No
- One Channel Map :LCM
- Pillow Speaker Compatibility :No
- Port Block :No
- Public Display Mode :No
- RJP (Remote Jack Pack) Compatibility :NO
- USB Auto Playback :No
- USB Auto Playback+ :No
- Welcome Video :No
- HCAP (GEM / FLASH / HTML) :No
- Mutlicast Ready :No
- Pro:Centric Server :Not Available
- Pro:Centric Data Streaming (IP) :No
- Pro:Centric Data Streaming (RF) :No
- Pro:Centric IP Return Path :No
- Pro:Idiom Media DRM :No
- Quick Menu Version :5
- Service Carousel (TLX, Firmware) :No
- Unicast Ready :No
- hqEnabledFlag :Yes
- Back Color :White
- Bezel Width (Off Bezel) :L/R/T: 23.3 mm, B: 59.7 mm
- Bezel Width (On Bezel) :L/R/T: 23.6 mm, B: 60.0 mm
- Credenza / Security Aperture :No
- Dimensions with Top Mount (W x H x D) :391.4 x 278.6 x 82.4 mm
- Kensington Lock :No
- Lock Down Plate :No
- Shipping Stand Type :Swing Arm Mount
- AI Picture Pro :No
- Brightness (Typ.) :Not Available
- Dynamic Vivid :No
- Game Optimizer :No
- Lifetime :Not Available
- Nano Cell Technology :No
- Panel Technology :Not Available
- CEC (Regulatory) :No
- Conformal Coating :No
- ETL :No
- FCC (Regulatory) :Yes
- ISO 22196 (Antimicrobial) :Yes
- NOM :No
- NRCan :No
- RoHS (Environmental) :No
- UL Certification :Yes
- Smart Auto Off / Sleep Timer :No
- DIAL :No
- Gallery Mode :No
- Home Office :No
- Magic Remote Compatibility :No
- Moving Picture Playback (SDD/Plus HD) :No
- Multi View :No
- Pre-loaded Apps :Yes
- Quick Access :No
- SDP Server Compatibility :Yes
- Soft AP :Yes
- SW Clock (World Clock / Alarm) :No
- SNMP :No
- Video Tag :No
- Wake on RF :No
- Wake-on-LAN (WOL) :No
- webRTC (Real Time Communication) :No
- System:Main Processor (SoC) :No
- Basic Accessories (included) :RF Jumper, Swing Arm Mount (RF, MPI, LAN, HDMI cable extensions), Jack Pack Cover
