- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www.lenovo.com
- Brand Name
- Lenovo
- Product Line
- ThinkStation
- Product Series
- P3 Gen 2
- Product Type
- Workstation
ThinkStation P Series Workstations
Designed to deliver cutting-edge performance, versatility and reliability for the affordable price of a desktop, the Lenovo ThinkStation P Series workstations are designed from the ground up for reliability and ease of use. With the ingenious modular design, making upgrades and customizations are effortless. It's a space-saving, powerful, and versatile workstation that is ideal for the most demanding of workflows, catering to your individual needs.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
3 Year On-site
- Technical Information
- AI-powered
- Yes
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Core Ultra 5
- Processor Model
- 235
- Processor Core
- Tetradeca-core (14 Core)
- Processor Threads
- 14
- Processor Speed
- 3.40 GHz
- vPro Technology
- Yes
- Processor Socket
- Socket LGA-1851
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- Q870
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR5 SDRAM
- Total Number of Memory Slots
- 2
- Error Checking
- Non-ECC
- Storage
- Drive Type
- SSD
- Total Solid State Drive Capacity
- 512 GB
- Solid State Drive Interface
- PCI Express NVMe 5.0 x4
- Solid State Drive Configuration
- 1 x 512GB
- Controllers
- Controller Type
- NVMe
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5
- Display & Graphics
- Graphics Controller Manufacturer
- Intel
- Graphics Memory Accessibility
- Shared
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Wireless LAN
- Yes
- Bluetooth
- Yes
- Interfaces/Ports
- HDMI
- Yes
- Total Number of USB Ports
- 7
- Number of USB 3.2 Gen 1 Ports
- 1
- Number of USB 3.2 Gen 2 Ports
- 5
- USB Type-C
- Yes
- USB Type-C Detail
- 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only
- DisplayPort
- Yes
- Number of HDMI Outputs
- 1
- Number Of Ethernet Ports
- 1
- Number of DisplayPort Outputs
- 1
- Optional Ports
Details regarding optional ports aggregated from the information available for this product's family/series. | Optional Rear Ports (configured)
- Punch out port 1 (one of VGA / DisplayPort™ / HDMI® 4K / HDMI® 8K / serial / USB-C® 5Gbps with DisplayPort™ and PD 3.0 functions / RJ-45)
- Punch out port 2 (one of VGA / DisplayPort™ / Thunderbolt™ 4 / HDMI® 4K / HDMI® 8K / serial / RJ-45)
- 2x USB-A (USB 10Gbps / USB 3.2 Gen 2), occupies port 1 and 2
- 4x USB-A (USB 10Gbps / USB 3.2 Gen 2), share 10Gbps bandwidth, occupy port 1 and 2
- 2x GbE RJ-45, via additional PCIe® adapter
- 4x GbE RJ-45, via additional PCIe® adapter
- 4x serial (via 4-port serial expansion card, PCIe® x1)
- Input Devices
- Keyboard Localization
- French (Canada)
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows 11 Pro
- Operating System Language
- French
- Operating System Architecture
- 64-bit
- Power Description
- Maximum Power Supply Wattage
- 230 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Tiny
- Height
- 1.46" (37 mm)
- Width
- 7.05" (179 mm)
- Depth
- 7.20" (182.90 mm)
- Weight (Approximate)
- 3.09 lb (1400 g)
- Miscellaneous
- Package Contents
- ThinkStation P3 Tiny Gen 2
- AC Adapter
- Keyboard
- Mouse
- TCO Certified
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- TCO Certified 10.0
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
