- General Information
- Manufacturer
- IOGEAR, Inc
- Manufacturer Website Address
- http://www.iogear.com
- Brand Name
- IOGEAR
- Product Line
- Quantum
- Packaged Quantity
- 1
- Product Type
- Docking Station
The Future of High-Speed Connectivity
Experience the next generation of connectivity with Thunderbolt™ 5. Enjoy blazing-fast data transfer speeds of up to 80Gbps, connect multiple high-resolution displays, and charge your laptop with up to 140W of power delivery.
Your Vision, Amplified
Immerse yourself in stunning visuals with support for up to dual 8K displays or triple 4K displays. Whether you're editing 8K video, designing complex graphics, or simply multitasking, the Quantum Thunderbolt™ 5 Dock Pro delivers the ultimate visual experience.
Connect Your World, Effortlessly
Stay connected to all your devices with a comprehensive range of ports, including Thunderbolt™ 5, USB-A, 2.5 gbEthernet, and a 3.5mm audio jack. Whether you're plugging in a keyboard, mouse, external hard drive, or network cable, the Quantum Thunderbolt™ 5 Dock Pro has you covered.
Power Your Day
Keep your laptop charged and ready to go with up to 140W of power delivery. No more worrying about low battery life, focus on your work and let the Quantum Thunderbolt™ 5 Dock Pro handle the rest
Seamless Collaboration, Simplified
Boost your productivity and streamline your workflow with Thunderbolt™ Share. Effortlessly share files, peripherals, and even your screen between two PCs.
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Connectivity Technology
- Wired
- Charging Capability
- Yes
- Device Supported
- Mouse
- Hard Drive
- Keyboard
- Notebook
- Desktop PC
- Memory Card Reader
- Yes
- Memory Card Supported
- SD
- Features
- Power Delivery Pass-through
- Card Reader
- Number of Displays Supported
- 3
- Screen Mode Supported
- 8K
- 4K
- 8K @ 60Hz
- 4K @ 144Hz
- Supported Resolutions
- 7680 x 4320
- 3840 x 2160
- Maximum Data Transfer Rate
- 10 GB/s
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Interfaces/Ports
- Host Interface
- Thunderbolt 5
- Total Number of USB Ports
- 7
- USB Type-A
- Yes
- Number of USB Type-A Ports
- 4
- USB Type-C
- Yes
- USB Type-C Detail
- 2x USB-C Thunderbolt™ 5(15W PD) 1x USB-C Thunderbolt™ 5 (60W)
- Network (RJ-45)
- Yes
- Number of RJ-45 Ports
- 1
- Headphone/Microphone Combo Port
- Yes
- Thunderbolt
- Yes
- Thunderbolt Ports Quantity
- 3
- USB Power Delivery
- 140W
- Software
- Operating System Supported
- Windows 11
- Windows 10
- macOS Sonoma 14.4
- macOS Sequoia 15
- Power Description
- Maximum Power Supply Wattage
- 180 W
- Power Source Type
- Power Adapter
- Physical Characteristics
- Height
- 1.20"
- Width
- 8.90"
- Length
- 3.6"
- Weight (Approximate)
- 1.60 lb
- Miscellaneous
- Package Contents
- Quantum Docking Station
- 1 x Thunderbolt 5 Cable
- 1 x Power Adapter
- 1 x Quick Start Guide
- 1 x Warranty Card
- System Requirements
PC OS requirements
- Thunderbolt 5: Windows 11
- Thunderbolt 5: macOS 14.4+
- macOS users on M4, M1 Pro /M2 Pro /M3 Pro/ M4 Pro, M1 Max/M2 Max/M3 Max/M4 Max, M1 Ultra/M2 Ultra, or Intel based Macs can connect up to dual displays.
- M1/M2/M3 Macs are limited to 1 external Display by Macbook internal design.
- Windows PC Thunderbolt 5 and Thunderbolt 4 users can connect up to dual displays.
- macOS DOES NOTsupport Triple monitors via a Thunderbolt Docking Station
- Windows PC Thunderbolt 5 users can connect up to three displays on supported host computers.
- Windows PC Thunderbolt 4 are limited to 2 displays and users cannot connect three displays.
- 1x Thunderbolt™ 4 or 5 port
- Windows 11
- 1x Thunderbolt™ 4 or 5 port
- Windows 11
macOS® requirements
Dual Monitors
Triple Monitors
Thunderbolt™ Share Requirements:
Host Computer:
Downstream (Second) Computer:
- TAA Compliant
- Yes
