- General Information
- Manufacturer
- IOGEAR, Inc
- Manufacturer Website Address
- http://www.iogear.com
- Brand Name
- IOGEAR
- Packaged Quantity
- 1
- Product Type
- KVM Switchbox
Enhance High-End Multi-Monitor Workstation
Maximize your high-end dual DisplayPort workstations by connecting them to the 4-Port 4K Dual View Display Port KVMP. Experience 4K Cinema resolutions along with rich bass and 7.1 surround sound while switching between both computers and sharing two USB 3.0 peripherals with the push of a button.
A Dual Cinema 4K Experience
Join two Cinema 4K DisplayPort monitors to your premium desktop or laptop to experience superior screen, image, and video quality. The Dual View DisplayPort KVMP delivers a Cinema 4K resolution standard of 4096 x 2160 at a frame rate of 60Hz.
Designed for professional film and video production industries, the 4-Port KVMP supports environments requiring cinematic graphics resolution. Superior quality is also ideal for applications in motion graphic design, animation, engineering, architecture, and media design.
Convenient Switching Methods
Switch and access two DisplayPort computers from the push-button front panel or hotkey combination on your keyboard. Utilize the latest in mouse port-switching functionality to change ports by simply clicking the wheel button on your 3-button USB mouse.
Expand to Utilize Up to Four 4K Monitors
Tackle large projects and double your desktop viewing space by adding a second 4-Port KVMP (GCS1944). Expand your workstations to accommodate up to four 4K Cinema DisplayPort monitors.
Smart Connectivity
Additional smart connectivity features turn your workstation into a convenient, easy-to-use powerhouse. The Power on Detection ensures automatic connection to the next powered-on computer. With Multi-Stream Transport (MST) support, double your desktop viewing space by daisy chaining each monitor to another monitor, accommodating up to four DisplayPort monitors*. The built-in USB 3.0 ports provide connectivity speeds up to 5Gbps and compatibility with legacy USB 2.0 and 1.1 devices.
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Number of Computers Supported
- 4
- Number of Local Users Supported
- 1
- Video
- Maximum Video Resolution
- 4096 x 2160
- Interfaces/Ports
- USB
- Yes
- DisplayPort
- Yes
- Number of USB Ports
- 8
- Number of DisplayPorts
- 10
- Physical Characteristics
- Form Factor
- Desktop
- Height
- 2.1"
- Width
- 13.9"
- Depth
- 6.1"
- Weight (Approximate)
- 3.55 lb
- Miscellaneous
- Package Contents
- 4-Port 4K Dual View DisplayPort KVMP with USB 3.0 Hub and Audio (TAA)
- 8 x DisplayPort Cables
- 4 x USB 3.0 Cables
- 4 x Audio Cable Set
- 1 x Power Adapter
- 1 x Manual
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Country of Origin
- Taiwan
- TAA Compliant
- Yes
