- General Information
- Manufacturer
- Hikvision
- Manufacturer Website Address
- http://www.hikvision.com
- Brand Name
- Hikvision
- Product Line
- ColorVu
- Product Series
- Ultra
- Product Type
- Network Camera
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 131.23 ft
- Night Vision Type
- Infrared/Color
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/3"
- Color Supported
- Color
- Field of View
- horizontal FOV 100.2°, vertical FOV 54.7°, diagonal FOV 119.7°
- Effective Camera Resolution
- 4 Megapixel
- Video
- Video Formats
- H.265
- H.265 (MP)
- H.264
- H.264 (MP)
- H.264 BP
- H.264 HP
- H.264+
- H.265+
- MJPEG
- Maximum Video Resolution
- 2688 x 1520
- Maximum Frame Rate
- 30 fps
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 2.80 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/1
- Exposure
- Shortest Shutter Speed
- 1/100000 Second
- Longest Shutter Speed
- 1/3 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP/IP
- ICMP
- HTTP
- HTTPS
- FTP
- DHCP
- DNS
- DDNS
- RTP
- RTSP
- NTP
- UPnP
- SMTP
- IGMP
- 802.1X
- QoS
- IPv4
- IPv6
- UDP
- Bonjour
- SSL/TLS
- PPPoE
- SFTP
- ARP
- SNMP
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Turret
- Durability
- Corrosion Resistant
- Dust Resistant
- Color Family
- White
- Product Color
- White
- Diameter
- 5"
- Weight (Approximate)
- 1.21 lb
- Environmental Conditions
- Minimum Operating Temperature
- -22°F (-30°C)
- Maximum Operating Temperature
- 140°F (60°C)
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- SD Card Local Storage
- Built-in Microphone
- Motion Detection
- Human Detection
- Vehicle Detection
- Cross Line Detection
- Tampering Alarm
- Privacy Masking
- Wide Dynamic Range
- Day/Night
- Ingress Protection Rating
- IP67
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
