- General Information
- Manufacturer
- Fractal Design
- Manufacturer Website Address
- http://www.fractal-design.com
- Brand Name
- Fractal Design
- Product Line
- Meshify 3 XL
- Package Type
- Retail
- Product Type
- Gaming Computer Case
Enhanced performance in a generous format
Advanced airflow
Access performance engineering in a spacious format, with ample ventilation and an air guide which helps keep components running cool.
Evolved design
Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel.
White
Black
Designed for gaming
Create a powerful gaming system with space for graphics cards up to 512 mm in length and E-ATX (330 mm) motherboard compatibility.
Ambience Pro RGB Version
Enhanced lighting
Create the right atmosphere with advanced ARGB Gen 2 ambient lighting, including an animated PC startup effect.
Ambience Pro RGB Version
Tailored experience
Customize your lighting and fans easily with a download-free configuration tool, accessed via the included Adjust Pro Hub.
Easily accessible
Enjoy a smooth build experience with easily removable panels, including a sliding top panel featuring a fabric tab.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Motherboard Supported
- EATX
- ATX
- ITX
- EE-ATX
- SSI EEB
- SSI CEB
- Mini ITX
- Micro ATX
- Number of Fans Supported
- 10
- Fan Supported Details
Front Fan:
- 3 x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)
Top Fan:
- 3 x 120/140 mm
Rear Fan:
- 1 x 120/140 mm
- Number of Fans Installed
- 3
- Fan Size Supported
- 4.72"
- 5.51"
- 7.09"
- Installed Fan Size
- 5.51"
- Installed Fan Size Details
- 3 × 140mm
- Features
- Dust Filter
- Window Panel
- Yes
- Window Panel Location
- Left Side
- Bays
- Number of Internal 3.5" Bays
- 2
- Number of Internal 2.5" Bays
- 4
- Number of Total Expansion Bays
- 6
- I/O Expansions
- Total Number of Expansion Slots
- 7
- Interfaces/Ports
- Total Number of USB Ports
- 3
- USB Port Details
- 2 x USB 3.2 Gen 1 Type-A
- 1 x USB 3.2 Gen 2x2 Type C
- Front USB
- Yes
- Total Number of Audio In Ports
- 1
- Front Audio In
- Yes
- Total Number of Audio Out Ports
- 1
- Front Audio Out
- Yes
- Microphone
- Yes
- Headphone/Microphone Combo Port
- Yes
- Power Description
- Power Supply Installed
- No
- Physical Characteristics
- Color Family
- White
- Product Color
- White
- Tinted
- Product Material
- Mesh
- Steel
- Tempered Glass
- Cooler Type
- Fan/Liquid Cooler
- Form Factor
- Full-tower
- Maximum CPU Cooler Height
- 7.17"
- Maximum PSU Length
- 9.06"
- Maximum GPU Length
- 20.16"
- Height
- 20.3"
- Width
- 9.6"
- Depth
- 22.6"
- Weight (Approximate)
- 25.13 lb
- Miscellaneous
- Package Contents
- Computer Case Meshify 3 XL
- Manual
- Red Note
- Accessory Box (4 x PSU Screws, 12 x MB Screws, 20 x SSD Screws M3, 5 x Zip Tie, 8 x HDD Rubber, 4 x MB Standoff, 8 x HDD Screws, 1 x 500 mm Fractal Connect Cable, Legacy Splitter Cable)
