AN UNPRECEDENTED 750 WATT SFX PSU
The most powerful SFX power supply in the market, perfect for the most power-dense small-form-factor PCs.
80 PLUS PLATINUM CERTIFIED
The SF750 Platinum delivers power at up to 92% efficiency, lowering energy consumption, noise, temperatures, and your power bill.
JAPANESE 105°C CAPACITORS
Using high-end electrolytic capacitors, the SF750 Platinum offers the unwavering power and long-term reliability you demand from a CORSAIR power supply.
ZERO RPM FAN MODE
The SF750 Platinum's 92mm cooling fan doesn't spin until you need it, for near-silent operation at low and medium loads.
92MM PWM LOW NOISE COOLING FAN
Utilizing PWM instead of the standard DC voltage control, the SF750 Platinum keeps noise low and delivers precise fan speed. The SF750 Platinum also utilizes a copper alloy heatsink, ensuring optimal thermal performance.
FULLY MODULAR CABLES
SF Platinum Series power supplies come equipped with premium, individually sleeved cables featuring a flexible paracord sleeve, ready to fit right into your new high-end PC. The individually sleeved cables also make routing and cable management a breeze, with a lower profile and improved flexibility.
SFX-TO-ATX BRACKET INCLUDED
SF Platinum Series power supplies include an SFX-to-ATX power supply adapter bracket enabling installation into any ATX compatible case.
SEVEN-YEAR WARRANTY
CORSAIR offers a seven-year warranty on all SF Platinum Series power supplies, your guarantee of reliable operation that will last across several system builds. If you need help, CORSAIR customer service and tech support are always on hand.
- General Information
- Manufacturer
- Corsair
- Manufacturer Website Address
- http://www.corsair.com/us/
- Brand Name
- Corsair
- Product Series
- SF
- Product Type
- Power Supply
- Warranty
- Limited Warranty
- 7 Year
- Technical Information
- Specification Compliance
- ATX12V/EPS12V
- Efficiency
- 92%
- Number of Fans
- 1
- Modular
- Yes
- Power Description
- Number of +12V Rails
- 1
- Input Voltage
- 120 V AC
- 230 V AC
- Output Voltage
- 3.3 V DC
- 5 V DC
- 12 V DC
- Output Voltage Detail
- 5 V DC @ 20 A
- 12 V DC @ 62.5 A
- 12 V DC @ 300 mA
- 5 V DC @ 2.5 A
- Output Current
- 20 A
- 62.50 A
- 300 mA
- 2.50 A
- Output Power
- 750 W
- Physical Characteristics
- Form Factor
- Internal
- Height
- 3.9"
- Width
- 2.5"
- Depth
- 4.9"
- Weight (Approximate)
- 1.98 lb
- Miscellaneous
- Package Contents
- SF750 Power Supply
- AC Power cord
- DC Modular Cable Set
- DC Modular Cable Storage Bag
- Cable Ties
- Corsair Case Badge
- User Manual
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- 80 Plus Platinum
