Highly available single phase UPS features redundant and scalable double-conversion on-line power protection
- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Symmetra
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 2 Year
- Additional Warranty Information
2 years repair or replace, optional on-site warranties available, optional extended warranties available
- Technical Information
- Plug/Connector Type
- NEMA L6-30P
- Receptacle Type
- NEMA L6-20R
- NEMA L6-30R
- Receptacle Detail
- 2 x NEMA L6-20R
- 1 x NEMA L6-30R
- Cord Length
- 6 ft
- Phase
- Single Phase
- Application/Usage
- Server
- Power Description
- Load Capacity (VA)
- 6000 VA
- Input Voltage
- 230 V AC
- Input Current
- 30 A
- Output Voltage
- 208 V AC
- Waveform Type
- Sine Wave
- Battery Information
- Battery Chemistry
- Lead Acid
- Typical Battery Recharge Time
- 4 Hour
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 14"
- Width
- 19"
- Depth
- 28.7"
- Rack Height
- 8U
- Form Factor
- Rack-mountable
- Mounting Preference
- Lower
- Mounting Location
- Front
- Weight (Approximate)
- 99.21 lb
- Miscellaneous
- For Country/Region
- United States
- Package Contents
- Symmetra 6000VA Rack-mountable UPS
- User Manual
- Rack Mounting Brackets
- Rack Mounting Support Rails
- CD with Software
- Additional Information
- No Batteries Or Power Modules are included
- This is a Bare Frame
- Certifications & Standards
CSA
- Optimized Energy Efficiency
- Yes
- Product Take Back Program
- Yes
- RoHS Exemption Information
- https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SYHF6KT_ROHS_DECLARATION&p_FileName=SYHF6KTKIT_ROHS_DECLARATION_US.pdf
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=766368&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=766368&lang=en-us
- REACH free of SVHC
- No
- Lead Free
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
